Внешний диаметр и масса кг/км магистральных кабелей ТЗГ ТЗБ ТЗБл ТЗБГ ТЗК
|
Число четверок |
ТЗГ |
ТЗБ |
ТЗБл |
ТЗБГ |
ТЗБлГ |
ТЗК |
|
D / g |
D / g |
D / g |
D / g |
D / g |
D / g |
|
Сечение жилы D = 0,9 мм |
|
4 |
12,3/658 |
22,4/1073 |
23,5/1138 |
18,0/900 |
19,0/956 |
|
|
7 |
14,6/905 |
26,1/1515 |
27,1/1586 |
21,7/1311 |
22,7/1372 |
33,6/3819 |
|
12 |
18,8/1279 |
30,2/1979 |
31,2/2060 |
25,8/1740 |
26,8/1811 |
37,8/4096 |
|
14 |
19,8/1441 |
31,5/2162 |
32,5/2244 |
27,1/1910 |
28,1/1985 |
39,0/4331 |
|
19 |
22,1/1785 |
34,5/2555 |
35,5/2645 |
30,1/2278 |
31,1/2361 |
42,0/4945 |
|
27 |
26,8/2378 |
38,7/3177 |
39,7/3279 |
34,3/2865 |
35,3/2958 |
46,3/5906 |
|
37 |
30,32976 |
42,8/3855 |
43,8/3967 |
38,4/3507 |
39,4/3611 |
50,4/6891 |
|
52 |
35,7/3916 |
48,4/4889 |
49,4/5015 |
44,0/4494 |
45,0/4612 |
|
|
61 |
38,2/4592 |
51,5/5581 |
52,5/7515 |
47,1/5159 |
48,1/5285 |
|
|
80 |
43,5/5795 |
57,2/6919 |
58,2/7070 |
52,8/6449 |
53,8/6590 |
|
|
102 |
49,6/7211 |
64,2/9075 |
65,2/9251 |
59,8/8546 |
60,8/8712 |
|
|
114 |
51,67972 |
67,0/9903 |
68,0/10084 |
62,6/9348 |
63,6/9520 |
|
|
Сечение жилы D = 1,2 мм |
|
4 |
16,2/919 |
26,4/1550 |
27,4/1611 |
22,0/1339 |
23,0/1396 |
33,9/3362 |
|
7 |
19,41197 |
29,5/1936 |
30,5/2013 |
25,1/1703 |
26,1/1771 |
37,1/3996 |
|
12 |
25,2/1874 |
35,2/2661 |
36,2/2757 |
30,8/2378 |
31,8/2467 |
42,7/5063 |
|
14 |
26,2/2085 |
36,1/2854 |
37,1/2954 |
31,7/2565 |
32,7/2655 |
43,6/5359 |
|
19 |
30,2/2619 |
40,0/3447 |
41,1/3556 |
35,6/3124 |
36,6/3224 |
47,6/6272 |
|
27 |
35,4/3482 |
45,3/4402 |
46,3/4525 |
40,9/4033 |
41,9/4146 |
52,8/7626 |
|
37 |
41,0/4514 |
50,8/5519 |
51,8/5656 |
46,4/5103 |
47,4/5232 |
58,4/9188 |
|
52 |
47,0/6046 |
56,8/7157 |
57,8/7309 |
52,4/6690 |
53,4/6833 |
|
|
61 |
51,5/6986 |
62,5/8819 |
63,5/8992 |
58,1/8303 |
59,1/8467 |
|
|
|
